MIL-DTL-5099C
TABLE III. Sampling plan A.
Quantity offered for
Quantity to be selected
acceptance
for inspection
First 15
See Note 1
Next 50
1
Next 75
1
Next 100
1
Each additional 200
1
or fraction thereof
1
When sampling plan B is invoked, the quantity shall be zero.
When sampling plan B is to be omitted, the quantity shall be one.
4.3.2.1.1 Sampling plan A inspection. Each sample selected for sampling plan A
inspection shall be subjected to the tests as shown in table II, in the order listed.
4.3.2.2 Sampling plan B sample selection. When required by the procurement contract,
2 indicators shall be selected at random from the first 15 produced on contract (see 6.2).
4.3.2.2.1 Sampling plan B inspection. Each indicator selected for sampling plan B
inspection shall be subjected to the tests as shown in table II, in the order listed.
4.4 Inspection conditions.
4.4.1 Standard conditions. Unless otherwise specified, all inspections required by this
specification shall be made under the following conditions:
Room ambient: 25 ±5 °C (77 ±9 °F).
Temperature
Pressure
Normal atmospheric: Approximately 29.92 inches mercury (Hg). When
tests are made with atmospheric pressure substantially different from the
above values, proper allowance for change in indicator reading shall be
made for the difference from the specified conditions.
Humidity
Room ambient: 40 to 90 percent relative humidity.
4.4.2 Test readings. Unless otherwise specified, before a test reading is taken, the
indicator shall be tapped using a vibrator set at 60 Hertz (Hz) with a maximum double amplitude
of 0.002 inch.
4.4.3 Attitude. Unless otherwise specified, the indicator shall be tested in its normal
operating position.
4.5 Test methods.
4.5.1 Examination of product. Each indicator shall be examined externally to determine
conformance with the applicable drawings and with all the requirements of this specification not
covered by tests.
11
