MIL-PRF-62430B
4.3.1 Failure. Deficiencies found during, or as a result of, first article inspection shall be cause
for rejection.
4.4 Conformance inspections.
4.4.1 Sampling for examination. Sampling for quality conformance inspection shall be
done in accordance with general inspection level II of ANSI/ASQ Zl.4.
4.4.2 Examination. The harnesses shall be examined for the defects listed in table II.
One or more defects shall be cause for rejection.
TABLE II. Classification of defects.
Method of
examination
Category
Defect
Major:
101
Assembly incomplete (see 3.4.1).
Visual
102
Dimensions affecting interchangeability, out of tolerance
SIE 1/
(see 3.4.1).
103
Weight not as specified (see 3.4.2).
SIE
104
Thermocouple probes not as specified (see 3.4.3).
Visual and
SIE
105
Individual circuit resistance not as specified (see 3.5.1).
SIE
106
Average circuit resistance not as specified (see 3.5.2).
SIE
107
Sensing probe sheath leakage greater than specified
SIE
(see 3.5.5).
Minor:
201
Dimensions not affecting interchangeability out of
SIE
tolerance (see 3.4.1).
202
Marking improper (see 3.7).
Visual
1/ SIE = Standard Inspection Equipment.
4.4.3 Acceptance tests (100%). Each harness shall be subjected to the acceptance tests
specified in table I.
4.4.3.1 Failure. Failure of any harness to pass any of the acceptance tests shall be cause
for rejection of the failed item.
4.5 Methods of inspection.
4.5.1 Materials and construction. Conformance to 3.3 through 3.4.3 shall be determined
by inspection of contractor records providing proof or certification that design, construction,
10
