MIL-DTL-6508C
Marking
Height or length
Width or line
Material or finish
(±0.016)
graduation
(±0.005)
Numerals
0.125
0.020
Lusterless white
or
Graduations at 10-degree
0.156
0.020
fluorescent luminescent
divisions
material
Pointer (shaded part)
As shown
-
Graduations at 2-degree
0.094
0.015
divisions
Lettering (FREE AIR, °C)
0.094
0.015
Background of dial
-
-
Lusterless black
MS PART NO.
0.094
-
Pointer (unshaded part)
As shown
-
NOTES:
1. Dimensions are in inches.
2. Unless otherwise shown, all tolerances are ±0.010.
3. All dial graduations are partial radial lines.
4. Numerals and letters shall be in accordance with MS33558.
5. Pointer dimensional limits are in accordance with 3.6.6.
FIGURE 1. Dial.
6
